Icom ID-5100A Full Manual

6
D-STAR OPERATION <BASIC>
6-9
Accessingrepeaters
This section describes how to check whether or not you
can access your local area repeater (Access repeater),
and if your signal is successfully sent to a destination
repeater.
If your call sign (MY) has not been set, or your call
sign and equipment have not been registered at a
D-STAR repeater, see page 6-5 to 6-7.
Select your Access repeater (“FROM”)1.
Touch [DR]. q
Check whether or not “FROM” is selected. w
• If “FROM” is not selected, touch the “FROM” eld.
Touch the “FROM” field. e
• Opens the “FROM SELECT” screen.
Touch “Repeater List. r ”
• Opens the “REPEATER GROUP” screen.
Touch the repeater group where your access repeat- t
er is listed. (Example: “11: Japan”)
Touch your access repeater. (Example: “Hirano”) y
• Returns to the DR screen, and the selected repeater
name is displayed in “FROM.”
Even if you select just the repeater name, the repeat-
er call sign, its frequency, duplex setting, frequency
offset and Gateway call sign are automatically set.
SelecttheDestinationrepeater(“TO”)2.
Touch the “TO” field. u
• Check whether “TO” is selected.
Touch the “TO” field again. i
• Opens the “TO SELECT” screen.
Touch “Gateway CQ. o ”
• Opens the “REPEATER GROUP” screen.
!0 Touch the repeater group where your destination re-
peater is listed. (Example: “11: Japan”)
!1 Touch your destination repeater.
(Example: “Hamacho”)
• Returns to the DR screen, and the selected repeater
name is displayed in “TO.”
Continued on the next page. ☞
