Icom ID-5100A Full Manual

7
D-STAR OPERATION <ADVANCED>
7-17
Digital squelch functions (Continued)
D Thedigitalcodesquelchsetting
Touch [DR]. q
• Opens the DR screen.
Touch the Function group icon one or more times. w
• Selects the D-3 menu.
Touch [DSQL]. e
Touch “CSQL r S” or “CSQL”.
• CSQLS: Turns ON the digital code squelch function
with the Pocket beep.
- “CSQLS” appears.
• CSQL: Turns ON the digital code squelch function.
- “CSQL” appears.
Appears
Touch [MENU]. t
Touch “Digital Code.” y
(DUP/TONE... > DigitalCode)
Touch u [+] or [–] one or more times to select the digital
code.
Touch [MENU]. i
• Closes the Menu screen.
When the received signal includes a matching code, the
squelch opens and you can hear the audio.
• When the received signal does not include a matching code,
the digital code squelch does not open. However, the S/RF
meter displays the signal level.
NOTE:
Even if the squelch closes by the digital code squelch
function, you can receive the low-speed data.
D Digital code squelch function with a
Pocketbeep
When a received signal matches your digital code,
beeps sound for 30 seconds and an “S” blinks.
Within 30 seconds, push [PTT] to answer, or touch the
screen to stop the beeps and turn OFF the Pocket beep
function.
• “S” disappears.
If you make no operation for 30 seconds, the beeps
automatically stop, but “S” continues to blink to indi-
cate that you received a call.
Beep,Beep,Beep...
