Icom ID-5100A Full Manual

11
REPEATER AND DUPLEX OPERATIONS
11-6
Autorepeaterfunction
When the operating frequency falls within the repeater
output frequency range, the Auto Repeater function au-
tomatically sets the repeater settings (duplex ON/OFF,
duplex direction, tone encoder ON/OFF).
The Auto repeater function uses the preset repeater
tone frequency and frequency offset.
See page 12-12 for details of the setting.
Touch [MENU]. q
Touch “Auto Repeater.” w
(Function > Auto Repeater)
• If the item is not displayed, touch [∫] or [√] one or more
times to select another page.
Touch the desired option to turn ON the Auto Re- e
peater function.
 USAversion:
• OFF: The Auto repeater function is OFF.
• ON (DUP): Turns ON only the duplex operation.
(Default)
• ON (DUP, TONE): Turns ON the duplex operation and
tone encoder
 Koreanversion:
• OFF: The Auto repeater function is OFF.
• ON: Turns ON the duplex operation and tone encoder.
(Default)
Touch [MENU] r
• Closes the Menu screen.
FortheU.S.A.andKoreanversions:
When turned ON, the Auto repeater function has pri-
ority over the manual duplex setting. If the transmit
frequency changes after setting, the Auto repeater
function may have changed the duplex setting.
D Frequencyrangeandoffsetdirection
•U.S.A.version
FREQUENCY RANGE SHIFT DIRECTION
145.200–145.495 MHz “DUP–” is set
146.610–146.995 MHz “DUP–” is set
147.000–147.395 MHz “DUP+” is set
442.000–444.995 MHz “DUP+” is set
447.000–449.995 MHz “DUP–” is set
•Koreanversion
FREQUENCY RANGE SHIFT DIRECTION
439.000–440.000 MHz “DUP–” is set
