Icom ID-5100A Full Manual

1
PANEL DESCRIPTION
1-9
Microphone (HM-207) (Continued)
D SettingfrequencyandMemorychannel
[Exampleforfrequencysetting]
First, push [VFO/MR• ] to select the VFO mode.
Toenterthe435.680MHzfrequency:
Push [4], [3], [5], [6], [8], [0], then [ENT]. ➥
Tochangethe435.680MHzto435.540MHz:
Push [•], [5], [4], [0], then [ENT]. ➥
Toenterthe433.000MHzfrequency:
Push [4], [3], [3], then [ENT]. ➥
[ExampleforMemorychannelsetting]
First, push [VFO/MR• ] to select the Memory mode.
ToselecttheMemorychannel‘5’:
Push [5] then [ENT]. ➥
