MENU SCREEN
12-12
DUP/TONEitems
Offsetfrequency (Default:0.600.00*)
DUP/TONE... > Offset Freq
Set the frequency offset for duplex (repeater) operation
to between 0 and 59.99500 MHz.
• The duplex shift direction (DUP–/DUP+) is set in the
duplex setting window that is displayed when you
touch [DUP] in the F-3 menu.
• If the DR function is selected before selecting this
item, editing is restricted.
* The default value may differ, depending on the fre-
quency band (selected as the Main band before enter-
ing the Menu screen) and the transceiver version.
RepeaterTone (Default:88.5)
DUP/TONE... > Repeater Tone
Select a CTCSS tone frequency for repeater access
and other functions. 50 tone frequencies (67.0–254.1
Hz) are selectable.
TSQLFreq (Default:88.5)
DUP/TONE... > TSQL Freq
Select a CTCSS tone frequency for the tone squelch or
the Pocket beep function.
50 frequencies (67.0–254.1 Hz) are selectable.
•Selectablerepeatertone/tonesquelch
frequencies
(Unit: Hz)
67.0
69.3
71.9
74.4
77.0
79.7
82.5
085.4
088.5
091.5
094.8
097.4
100.0
103.5
107.2
110.9
114.8
118.8
123.0
127.3
131.8
136.5
141.3
146.2
151.4
156.7
159.8
162.2
165.5
167.9
171.3
173.8
177.3
179.9
183.5
186.2
189.9
192.8
196.6
199.5
203.5
206.5
210.7
218.1
225.7
229.1
233.6
241.8
250.3
254.1
ToneBurst (Default:OFF)
DUP/TONE... > Tone Burst
Turn the Tone Burst function ON or OFF in the FM mode
when using tone squelch.
•OFF: When you transmit a signal that superimposes
the CTCSS tone, the other station may hear a
short burst of noise from their receiver, just af-
ter you stop transmitting.
•ON:
When you transmit a signal that superimposes the
CTCSS tone, the function mutes the noise from
being heard in the other station’s receiver.
DTCS Code (Default:023)
DUP/TONE... > DTCS Code
Select a DTCS (both encoder/decoder) code for the DTCS
squelch. A total of 104 codes (023–754) are selectable.
•SelectableDTCScodes
023
025
026
031
032
036
043
047
051
053
054
065
071
072
073
074
114
115
116
122
125
131
132
134
143
145
152
155
156
162
165
172
174
205
212
223
225
226
243
244
245
246
251
252
255
261
263
265
266
271
274
306
311
315
325
331
332
343
346
351
356
364
365
371
411
412
413
423
431
432
445
446
452
454
455
462
464
465
466
503
506
516
523
526
532
546
565
606
612
624
627
631
632
654
662
664
703
712
723
731
732
734
743
754
DTCS Polarity (Default:BothN)
DUP/TONE... > DTCS Polarity
Select the DTCS polarity to use for transmitting and
receiving.
• Both N: Normal polarity is used for both TX and RX.
• TN-RR: Normal polarity is used for TX; Reverse polar-
ity for RX.
• TR-RN: Reverse polarity is used for TX; Normal polar-
ity for RX.
• Both R: Reverse polarity is used for both TX and RX.
DTCS code’s polarity for transmitting or receiving can
be independently set with this item.
DigitalCode (Default:00)
DUP/TONE... > Digital Code
Select the desired digital code for digital code squelch.
A total of 100 codes (00–99) are selectable.
