Icom ID-5100A Full Manual

13
OTHER FUNCTIONS
13-9
The tone squelch opens only when you receive a signal
containing a matching DTCS code in the FM or FM nar-
row mode. You can silently wait for calls from others us-
ing the same tone. Also, a reversed tone squelch func-
tion will mute the squelch when you receive a signal
containing a matched DTCS code.
D DTCScodesettingandoperation
SettingtheDTCScode1.
Select the VFO mode. q
Select FM or FM-N (FM narrow) mode. w
Rotate [DIAL] to select a desired operating frequency. e
Touch [MENU]. r
Touch “DTCS Code.” t
(DUP/TONE... > DTCS Code)
• If the item is not displayed, touch [∫] or [√] one or more
times to select another page.
• Opens the “DTCS Code” screen.
Touch [+] or [–] to enter a desired tone squelch fre- y
quency, and then touch [].
• Select a DTCS code between 023 to 754.
Save and
return
Entered
DTCS code
Touch [MENU]. u
• Closes the Menu screen.
DTCSsquelchoperation
TheDTCScodeoperation2.
Touch the Function group icon one or more times. i
• Selects the F-3 menu.
Touch [TONE]. o
!0 Touch the desired DTCS code type.
• DTCSS: The DTCS squelch with the pocket
beep function is ON.
• DTCS: The DTCS squelch function is ON.
• DTCS-R: The reverse DTCS squelch function is
ON.
• “DTCS” is displayed when the DTCS squelch is ON.
( “DTCS-R” is displayed when the reverse DTCS squelch
is ON.)
!1 Holding down [PTT] and call a desired station.
Operate normally.
Beepssoundwhenacallisreceived.
If “DTCSS” is selected in step !0, beeps sound
for 30 seconds and the icon “S” blinks when a call
with the matched DTCS code signal is received.
Within 30 seconds, push [PTT] to answer, or touch ➥
the screen to stop the beeps. (“S” disappears)
After that, the transceiver selects the regular DTCS
squelch operation.
If you make no operation for 30 seconds, the beeps
automatically stop, but “S” continues to blink to
indicate that you received a call.
