Icom ID-5100A Full Manual

12
MENU SCREEN
12-17
<<REC Start>>
Voice Memo > QSO Recorder > <<REC Start>>
Touch “<<REC Start>>,” and then “Recording started.”
appears and voice recording starts.
While recording, “<<REC Stop>>” item is displayed.
To stop recording, touch “<<REC Stop>>.”
• Be sure to insert an SD card into the card slot.
• Once recording has started, the recording will con-
tinue, even if the transceiver is rebooted.
To stop the recording, touch “<<REC Stop>>.”
Play Files
Voice Memo > QSO Recorder > Play Files
Performs the following steps to play back the recorded
audio on the SD card.
Touch “Play Files” to display the folders on the SD
card.
• These folders contain the stored les.
Be sure to insert an SD card into the card slot.
Playingback
Touch the folder that includes the desired file to play q
back.
Touch the file to play back. w
• The “VOICE PLAYER” screen is displayed and the se-
lected file is played back.
• See “Operation while playing back” for forwording or re-
winding. (Section 10)
Push [MENU]. e
• Closes the Menu screen.
NOTE:
• The folder name is automatically created, as shown
in the example below:
Recording date is 2014/4/1
Folder name: 20140401
• The le name is automatically created, as shown in
the example below:
Recording date and time is 2014/4/1 15:30:00
Folder name: 20140401_153000
• The voice audio is recorded onto an SD card, and
saved in the “wav” format. (“wav,” is not displayed on
the transceiver’s screen.)
• The recorded voice audio can also be played back
with a PC.
REC Mode (Default:TX&RX)
Voice Memo > QSO Recorder > Recorder Set > REC
Mode
Records both the transmitted and received audio as the
default setting.
• TX&RX: Records both the transmitted and received
voice audio.
• RX Only: Records only the received voice audio.
Whentransmittedwhilerecording
When “OFF” is selected in File Split, the recording is
paused. After finishing the transmission, the recording
resumes.
When “ON” is selected in File Split, a new file is au-
tomatically created, and the transmitted voice audio is
recorded into the new one.
RXRECCondition (Default:SquelchAuto)
Voice Memo > QSO Recorder > Recorder Set > RX
REC Condition
Select whether or not the squelch status affects the RX
voice audio recording.
• Always: The transceiver always records the RX
voice audio regardless of the squelch
status.
• Squelch Auto: The transceiver records the RX voice
audio only when a signal is received
(the squelch is opened).
When the squelch closes while record-
ing, the recording will continue for 2
seconds, and then pause.
VoiceMemoitems(ForRecord/Playback)
