GPS OPERATION
8-7
Checking your GPS position (Continued)
D TXformat:D-PRSPosition(Mobile)
The following items are displayed when the caller’s TX
format is D-PRS Position (Mobile).
Compass
Displays the caller’s direction from
your position
Latitude Displays the caller’s latitude
Longitude Displays the caller’s longitude
GL
Displays the grid locator based on the
latitude and longitude of the caller’s
position.
ALT Displays the caller’s altitude
DST
Displays the caller’s distance from
your position
COURSE
Displays the caller’s direction over
ground
SPEED Displays the caller’s speed
Symbol Displays the caller’s D-PRS symbol
SSID Displays the caller’s SSID
GPS Time Stamp
Displays the time that the caller
acquired the position data.
Call sign
Displays the caller’s call sign (with
SSID)
D TXformat:D-PRSPosition(Base)
The following items are displayed when the caller’s TX
format is D-PRS Position (Base).
Compass
Displays the caller’s direction from
your position
Latitude Displays the caller’s latitude
Longitude Displays the caller’s longitude
GL
Displays the grid locator based on the
latitude and longitude of the caller’s
position.
ALT Displays the caller’s altitude
DST
Displays the caller’s distance from
your position
POWER Displays the caller’s TX power level
HEIGHT
Displays the height of caller’s antenna
GAIN Displays the gain of caller’s antenna
DIRECT
Displays the direction the caller’s an-
tenna was pointing
Symbol Displays the caller’s D-PRS symbol
SSID Displays the caller’s SSID
GPS Time Stamp
Displays the time that the caller
acquired the position data.
Call sign
Displays the caller’s call sign (with
SSID)
