Icom ID-5100A Full Manual

2
BASIC OPERATION
2-3
Selectingthewatchmode
The transceiver has two independent watch modes;
Dualwatch mode and Single watch mode.
Dualwatchmode
The Dualwatch mode uses the MAIN and SUB bands,
and you can simultaneously monitor both bands.
In the Dualwatch mode, both MAIN and SUB bands are
displayed side by side.
Touching [MAIN] or [SUB] for 1 second selects the Sin-
gle watch mode.
Singlewatchmode
The Single watch mode uses the A and B bands, in-
stead of the MAIN and SUB bands, and you can moni-
tor one of them at a time.
In the Single watch mode, only one of the A or B bands
is displayed.
Touching [A] or [B] for 1 second selects the Dualwatch
mode.
NOTE: The Dualwatch left side band becomes the A
band in the Single watch mode.
The Dualwatch right side band becomes the B band
in the Single watch mode.
MAINband SUBband
MAINbandSUBband
Leftsidebecomes
theAbandinSin-
glewatchmode
Aband
Rightsidebecomes
the B band in Sin-
glewatchmode
Aband
Bband
SelectingtheMAINorSUBband D
Touch [SUB] to toggle the displayed band between ➥
the MAIN band and the SUB band.
• [MAIN] will be highlighted to indicate the MAIN band.
Dualwatchmode
Singlewatchmode
SelectingtheAorBbands D
Touch [A] or [B] to toggle the displayed band between ➥
the A band and the B band.
• Either A or B will be highlighted to indicate which band is
now displayed.
