Icom ID-5100A Full Manual

12
MENU SCREEN
12-27
ItemName
GPS > GPS TX Mode > D-PRS > TX Format > Item >
Item Name
Enter an item station name of up to 9 characters.
Data Type (Default:LiveItem)
GPS > GPS TX Mode > D-PRS > TX Format > Item >
Data Type
Set the item station’s status.
Live Item: The item station is valid.
Killed Item: The item station is invalid.
Symbol (Default:Radio)
GPS > GPS TX Mode > D-PRS > TX Format > Item >
Symbol
The symbol is an icon which represents item station’s
means of transportation or location. The stored symbol
is transmitted in addition to the position data while in
the D-PRS mode.
Editingasymbol
In the “Symbol” screen, touch [QUICK]. q
Touch “Direct Input.” w
Touch [+] or [–] to select the first digit. e
• Usable characters: /, \, 0 to 9, A to Z
Touch [+] or [–] to select the second digit. r
• Usable characters: Alphanumeric characters and sym-
bols
Touch [SET]. t
• Sets the Symbol.
Selectingapresetsymbol
➥ In the “Symbol” screen, touch a desired Symbol.
• Touch [∫] or [√] one or more times to select the page.
• Sets the Symbol.
See page 12-21 for details of the symbol list.
Comment
GPS > GPS TX Mode > D-PRS > TX Format > Item >
Comment
Enter a comment.
The number of characters you can enter differs,
depending on the Data Extension and Altitude data
entry.
DataExtension Altitude
Characters
entered
(maximum)
OFF — 43 (Default)
OFF Entered 35
Course/Speed — 36
Course/Speed Entered 28
Power/Height/Gain/Directivity — 36
Power/Height/Gain/Directivity Entered 28
The symbol “ ” shows the transmittable comment
range. Please note that the characters that exceed the
range will not be transmitted.
Transmittable comment range display
(In case of up to 28 characters)
GPS items (Continued)
