Icom ID-5100A Full Manual

6
D-STAR OPERATION <BASIC>
6-35
For easy operation, the repeater list is preloaded into
your transceiver.
This section describes how to manually update the re-
peater list using an SD card.
You can download the latest repeater list from the Icom
website.
Downloadingthelatestrepeaterlist1.
q Access the following URL to download the latest
data.
http://www.icom.co.jp/world/support/download/firm/
index.html
• The latest repeater list (CSV; Comma Separated Values
file) and settings file (ICF file) are contained in the down-
loaded ZIP file.
FileName: 5100_USA_140401.zip (Example)
Depending on the
updated file date.
Depending on the version.
This instruction manual description uses the file
name “5100_USA_140401.zip,” for example.
w Unzip the ZIP file that you downloaded from the Icom
website.
The “5100_USA_140401” (Example) folder will be
created.
Continued on the next page ☞
ID-5100A/E’s latest repeater list and setting file are up-
loaded to “Cloning software(Rev. MM) and manuals” on
the Icom website screen.
• The displayed contents may differ.
Updatingtherepeaterlist
InsertingtheSDcardintoaPC2.
e Insert the SD card into the SD card drive on your
PC.
• Icom recommends that you format all SD cards to
be used with the transceiver, even preformatted SD
cards for PCs or other uses. (p. 9-4)
See page 9-4 for details on inserting and removing
the SD card.
SD card
Transceiver
to the external
card reader
PC
CopyingthelatestrepeaterlisttotheSDcard3.
r Double-click the “5100_USA_140401” (Example)
folder created in the same place where the down-
loaded file is saved.
t Copy the CSV file (Example: “5100_USA_Rpt_140401.
csv”) in the folder to [RptList] of the SD card.
[ID-5100] > [CSV] > [RptList]
The copied CSV file is placed here.
Double-
Click
Double-
Click
ID-5100A
ID-5100E
Cloning software(Rev. MM) and manuals
20MM/MM/MM
