Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 2:
General operation
DMM7510-901-01 Rev. B / May 2015 2-95
DMM measurement capabilities
The Model DMM7510 can make the following measurements:
• DC voltage measurements from 10 nV to 1000 V
• AC true RMS voltage measurements from 0.1 μV to 700 V
• DC current measurements from 1 pA to 10 A
• AC current measurements from 1 nA to 10 A
• 2-wire resistance measurements from 0.1 μΩ to 1 GΩ
• 4-wire resistance measurements from 0.1 μΩ to 1 GΩ
• Continuity measurements from 100 mΩ to 1 kΩ
• Frequency measurements up to a minimum of 1 MHz on voltage signals from 100 mV to 700 V
• Period measurements up to a minimum of 1 MHz on voltage signals from 100 mV to 700 V
• Diode measurements from 1 μV to 10 V
• 3-wire and 4-wire RTD measurements from -200 °C to 630 °C
• Thermistor measurements from -80 °C to 150 °C
• Capacitance measurements from 0.1 pF to 1000 μF
• V
input
and V
sense
measurements from 10 nV to 1000 V; the V
sense
measurements are only available
on the 100 mV, 1 V, and 10 V ranges
• Digitize voltage measurements from 10 μV to 1000 V
• Digitize current measurements from 1 nA to 10 A
Warmup time
After the Model DMM7510 is turned on, it must be allowed to warm up for at least 1½ hours to allow
the internal temperature to stabilize. If the instrument has been exposed to extreme temperatures,
allow extra warmup time.
High-energy circuit safety precautions
To optimize safety when measuring voltage in high-energy distribution circuits, read and use the
directions in the following warning.
Dangerous arcs of an explosive nature in a high-energy circuit can cause severe personal
injury or death. If the Model DMM7510 is connected to a high-energy circuit when set to a
current range or low resistance range, the circuit is virtually shorted. Dangerous arcing can
result even when the Model DMM7510 is set to a voltage range if the minimum voltage
spacing is reduced in the external connections.
The front and rear terminals of the instrument are rated for connection to circuits rated
Measurement Category II up to 300 V, as described in International Electrotechnical
Commission (IEC) Standard IEC 60664. This range must not be exceeded. Do not connect
the instrument terminals to CAT III or CAT IV circuits. Connection of the instrument
terminals to circuits higher than CAT II can cause damage to the equipment and severe
personal injury.
