Keithley DMM7510 Reference Manual

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-86 DMM7510-901-01 Rev. B / May 2015
dmm.digitize.coupling.acfrequency
This attribute allows you to optimize the amplitude to compensate for signal loss across the coupling capacitor
when AC coupling is selected.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Configuration script
Measure configuration list
1000
Usage
value = dmm.digitize.coupling.acfrequency
dmm.digitize.coupling.acfrequency = value
value
The frequency: 3 Hz to 1 MHz
Functions
dmm.FUNC_DC_VOLTAGE
dmm.FUNC_RESISTANCE
dmm.FUNC_ACV_FREQUENCY
dmm.FUNC_AC_VOLTAGE
dmm.FUNC_4W_RESISTANCE
dmm.FUNC_ACV_PERIOD
dmm.FUNC_DC_CURRENT
dmm.FUNC_DIODE
dmm.FUNC_DCV_RATIO
dmm.FUNC_AC_CURRENT
dmm.FUNC_CAPACITANCE
dmm.FUNC_DIGITIZE_CURRENT
dmm.FUNC_TEMPERATURE
dmm.FUNC_CONTINUITY
dmm.FUNC_DIGITIZE_VOLTAGE
Details
This command is only used when the digitize coupling type is set to AC.
For example, if you are measuring a 50 Hz signal, you could set this to 50 Hz to compensate for
voltage drop across the coupling capacitor.
Example
dmm.digitize.func = dmm.FUNC_DIGITIZE_VOLTAGE
dmm.digitize.coupling.type = dmm.COUPLING_AC
dmm.digitize.coupling.acfrequency = 50
Set the digitize function to voltage.
Set the coupling type to AC.
Set the frequency to 500 Hz.
Also see
dmm.digitize.coupling.acfilter (on page 8-85)
dmm.digitize.coupling.type (on page 8-87)
