8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter

Reference Manual

8-272 DMM7510-901-01 Rev. B / May 2015

Example

trigger.ext.reset()

trigger.extin.clear()

trigger.extout.logic = trigger.LOGIC_NEGATIVE

trigger.extout.stimulus = trigger.EVENT_EXTERNAL

trigger.extin.edge = trigger.EDGE_FALLING

Reset the external I/O port values to their defaults.

Clear any event triggers on the external in line.

Set the output logic to negative (it asserts a low pulse).

Set the stimulus to the external input.

Set the external input to detect a falling edge.

Also see

trigger.ext.reset() (on page 8-267)

trigger.extout.stimulus

This attribute selects the event that causes a trigger to be asserted on the external output line.

Type TSP-Link accessible Affected by Where saved Default value

Attribute (RW)

Yes

Restore configuration

Instrument reset

Power cycle

Digital I/O trigger N reset

Configuration script

trigger.EVENT_NONE

Usage

event = trigger.extout.stimulus

trigger.extout.stimulus = event

event

The event to use as a stimulus; see Details
