7½ Digit Graphical Sampling Multimeter Reference Manual Section 2:
DMM7510-901-01 Rev. B / May 2015 2-55
Examples in this manual
Many of the remote interface examples in this manual show only one function. The features may be
available for additional functions.
For example, many allow you to change the display digits.
The SCPI example shows only the DC voltage display digits command:
:DISPlay:VOLTage:DIGits 4
The example to change the number of displayed digits for TSP is shown as:
dmm.measure.func = dmm.FUNC_DC_VOLTAGE
dmm.measure.displaydigits = dmm.DIGITS_4_5
You can replace the SCPI VOLTage parameter or TSP dmm.FUNC_DC_VOLTAGE parameter with the
parameter for another function to set the display digits for that function.
The function parameters for SCPI are shown in the following table.
The function parameters for TSP are shown in the following table.
dmm.FUNC_DIGITIZE_CURRENT
dmm.FUNC_DIGITIZE_VOLTAGE
Display features
You can set the front-panel display to display the units of measure, number of digits, and customized
text messages for your applications.
Setting the number of displayed digits
You can change the number of digits that are displayed for measurement readings on the front panel
for some of the functions. For temperature, frequency, period, continuity, and capacitance, the
displayed digits are fixed and cannot be changed.
