8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
8-74 DMM7510-901-01 Rev. B / May 2015
dmm.digitize.analogtrigger.mode
This attribute configures the type of signal behavior that can generate an analog trigger event.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Configuration script
Measure configuration list
dmm.MODE_OFF
Usage
setting = dmm.digitize.analogtrigger.mode
dmm.digitize.analogtrigger.mode = setting
• Edge (signal crosses one level): dmm.MODE_EDGE
• Pulse (two complementary edge events meet a specified time constraint):
dmm.MODE_PULSE
• Window (signal enters or exits a window defined by two levels):
dmm.MODE_WINDOW
• No analog triggering:
Functions
dmm.FUNC_DIGITIZE_CURRENT
dmm.FUNC_DIGITIZE_VOLTAGE
Details
When edge is selected, the analog trigger occurs when the signal crosses a certain level. You also
specify if the analog trigger occurs on the rising or falling edge of the signal.
When pulse is selected, the analog trigger occurs when a pulse passes through the specified level
and meets the constraint that you set on its width. You also specify the polarity of the signal (above or
below the trigger level).
When window is selected, the analog trigger occurs when the signal enters or exits the window
defined by the low and high signal levels.
