6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-60 DMM7510-901-01 Rev. B / May 2015
[:SENSe[1]]:<function>:ATRigger:PULSe:CONDition
This command defines if the pulse must be greater than or less than the pulse width before an analog trigger is
generated.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
GReater
Usage
[:SENSe[1]]:<function>:ATRigger:PULse:CONDition <setting>
[:SENSe[1]]:<function>:ATRigger:PULse:CONDition?
<function>
The function to which the setting applies; see Functions
<setting>
The setting:
• The pulse width must be greater than the specified pulse width: GReater
•
The pulse width must be less than the specified pulse width: LESS
Functions
VOLTage[:DC]
RESistance
TEMPerature
VOLTage[:DC]:RATio
VOLTage:AC
FRESistance
CONTinuity
DIGitize:VOLTage
CURRent[:DC]
DIODe
FREQuency[:VOLTage]
DIGitize:CURRent
CURRent:AC
CAPacitance
PERiod[:VOLTage]
Details
Only available when the analog trigger mode is set to pulse.
Example
CURR:ATR:MODE PULSe
CURR:ATR:PULSe:COND LESS
Set the analog trigger for the current function to
pulse.
Set the condition to less.
Also see
[:SENSe[1]]:<function>:ATRigger:MODE (on page 6-59)
[:SENSe[1]]:<function>:ATRigger:PULSe:WIDTh (on page 6-63)
Analog triggering overview (on page 3-64)
