Keithley DMM7510 Reference Manual

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-196 DMM7510-901-01 Rev. B / May 2015
dmm.measure.threshold.range
This attribute indicates the expected input level of the voltage signal.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Configuration script
Measure configuration list
10 V
Usage
value = dmm.measure.threshold.range
dmm.measure.threshold.range = value
value
The range: 0.1 to 700; instrument selects nearest valid range (100 mV, 1 V, 10 V,
100 V, 700 V)
Functions
dmm.FUNC_DC_VOLTAGE
dmm.FUNC_RESISTANCE
dmm.FUNC_ACV_FREQUENCY
dmm.FUNC_AC_VOLTAGE
dmm.FUNC_4W_RESISTANCE
dmm.FUNC_ACV_PERIOD
dmm.FUNC_DC_CURRENT
dmm.FUNC_DIODE
dmm.FUNC_DCV_RATIO
dmm.FUNC_AC_CURRENT
dmm.FUNC_CAPACITANCE
dmm.FUNC_DIGITIZE_CURRENT
dmm.FUNC_TEMPERATURE
dmm.FUNC_CONTINUITY
dmm.FUNC_DIGITIZE_VOLTAGE
Details
The range setting conditions the signal. The instrument automatically selects the most sensitive
threshold range for the value you enter. For example, if you specify the expected input voltage to be
90 mV, the instrument automatically selects the 100 mV threshold range.
Example
dmm.measure.threshold.range = 50
Set the threshold range for the selected
function to 100 V.
Also see
dmm.measure.threshold.autorange (on page 8-194)
dmm.measure.threshold.level (on page 8-195)
