6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
6-36 DMM7510-901-01 Rev. B / May 2015
:CALCulate[1]:<function>:MATH:PERCent
This command specifies the reference constant that is used when math operations are set to percent.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
1
Usage
:CALCulate[1]:<function>:MATH:PERCent <n>
:CALCulate[1]:<function>:MATH:PERCent DEFault
:CALCulate[1]:<function>:MATH:PERCent MINimum
:CALCulate[1]:<function>:MATH:PERCent MAXimum
:CALCulate[1]:<function>:MATH:PERCent?
:CALCulate[1]:<function>:MATH:PERCent? DEFault
:CALCulate[1]:<function>:MATH:PERCent? MINimum
:CALCulate[1]:<function>:MATH:PERCent? MAXimum
The function to which the setting applies; see Functions
The reference used when the math operation is set to percent; the range is -1e12 to
+1e12
Functions
Details
This is the constant that is used when the math operation is set to percent.
The percent math function displays measurements as percent deviation from a specified reference
constant. The percent calculation is:
Where:
• Percent is the result
• Input is the measurement (if relative offset is being used, this is the relative offset value)
• Reference is the user-specified constant
Example
CALC:VOLT:MATH:PERC 50
Set the math operations for voltage to percent.
Set the percentage value to 50.
Also see
Calculations that you can apply to measurements (on page 3-7)
:CALCulate[1]:<function>:MATH:FORMat (on page 6-31)
:CALCulate[1]:<function>:MATH:STATe (on page 6-37)
