Keithley DMM7510 Reference Manual

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-100 DMM7510-901-01 Rev. B / May 2015
dmm.digitize.limit[Y].low.value
This attribute specifies the lower limit for limit tests.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Configuration script
Measure configuration list
−1
Usage
lowLimit = dmm.digitize.limit[Y].low.value
dmm.digitize.limit[Y].low.value = lowLimit
lowLimit
The low limit value of limit
Y
; the range is
−
1E+12 to 1E+12
Y
Limit number 1 or 2
Functions
dmm.FUNC_DC_VOLTAGE
dmm.FUNC_RESISTANCE
dmm.FUNC_ACV_FREQUENCY
dmm.FUNC_AC_VOLTAGE
dmm.FUNC_4W_RESISTANCE
dmm.FUNC_ACV_PERIOD
dmm.FUNC_DC_CURRENT
dmm.FUNC_DIODE
dmm.FUNC_DCV_RATIO
dmm.FUNC_AC_CURRENT
dmm.FUNC_CAPACITANCE
dmm.FUNC_DIGITIZE_CURRENT
dmm.FUNC_TEMPERATURE
dmm.FUNC_CONTINUITY
dmm.FUNC_DIGITIZE_VOLTAGE
Details
This command sets the lower limit for the limit Y test for the selected measure function. When limit Y
testing is enabled, this causes a fail indication to occur when the measurement value is less than this
value.
Example
This example enables limits 1 and 2 for digitize voltage measurements. Limit 1 is checking for
readings to be between 3 and 5 V, while limit 2 is checking for the readings to be between 1 and 7 V.
The auto clear feature is disabled, so if any reading is outside these limits, the corresponding fail is 1.
Therefore, if any one of the fails is 1, analyze the reading buffer data to find out which reading failed
the limits.
