Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 8:
TSP command reference
DMM7510-901-01 Rev. B / May 2015 8-197
dmm.measure.transducer
This attribute sets the transducer type for the temperature measurement function.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Configuration script
Measure configuration list
dmm.TRANS_THERMOCOUPLE
Usage
type = dmm.measure.transducer
dmm.measure.transducer = type
type
The transducer type:
• Thermocouple: dmm.TRANS_THERMOCOUPLE
• Thermistor: dmm.TRANS_THERMISTOR
• 3-wire RTD: dmm.TRANS_THREERTD
• 4-wire RTD:
dmm.TRANS_FOURRTD
Functions
dmm.FUNC_DC_VOLTAGE
dmm.FUNC_RESISTANCE
dmm.FUNC_ACV_FREQUENCY
dmm.FUNC_AC_VOLTAGE
dmm.FUNC_4W_RESISTANCE
dmm.FUNC_ACV_PERIOD
dmm.FUNC_DC_CURRENT
dmm.FUNC_DIODE
dmm.FUNC_DCV_RATIO
dmm.FUNC_AC_CURRENT
dmm.FUNC_CAPACITANCE
dmm.FUNC_DIGITIZE_CURRENT
dmm.FUNC_TEMPERATURE
dmm.FUNC_CONTINUITY
dmm.FUNC_DIGITIZE_VOLTAGE
Details
The transducer type determines the type of temperature measurement that is made. Each transducer
type has related settings that must also be set. For example, thermocouple measurements are only
made if the type is set is set to thermocouple. You also need to set the thermocouple type when
setting up a thermocouple. For a transducer type of four-wire RTD, you also set the RTD type.
Example
dmm.measure.func = dmm.FUNC_TEMPERATURE
dmm.measure.transducer = dmm.TRANS_THREERTD
dmm.measure.threertd = dmm.RTD_D100
Set the measure function to temperature.
Set the transducer type to 3-wire RTD.
Set the RTD type to D100.
Also see
dmm.measure.fourrtd (on page 8-154)
dmm.measure.thermistor (on page 8-191)
dmm.measure.thermocouple (on page 8-192)
dmm.measure.threertd (on page 8-193)
Temperature measurements (on page 2-120)
