7½ Digit Graphical Sampling Multimeter Reference Manual Section 8:
DMM7510-901-01 Rev. B / May 2015 8-311
trigger.model.setblock() — trigger.BLOCK_BRANCH_ONCE
This function causes the trigger model to branch to a specified building block the first time it is encountered in the
trigger model.
Type TSP-Link accessible Affected by Where saved Default value
Function Yes
Restore configuration
Instrument reset
Configuration script Not applicable
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_BRANCH_ONCE, branchToBlock)
The sequence of the block in the trigger model
The block number of the trigger model block to execute when
the trigger model first encounters this block
Details
The branch-once building block branches to a specified block the first time trigger model execution
encounters the branch-once block. If it is encountered again, the trigger model ignores the block and
continues in the normal sequence.
The once block is reset when trigger model execution reaches the idle state. Therefore, the
branch-once block always executes the first time the trigger model execution encounters this block.
Example
trigger.model.setblock(2, trigger.BLOCK_BRANCH_ONCE, 4)
When the trigger model reaches block 2, the trigger model goes to block 4 instead of going in the default
Also see
Once block (on page 3-86)
trigger.model.setblock() —
trigger.BLOCK_BRANCH_ONCE_EXCLUDED
This function defines a trigger model block that causes the trigger model to go to a specified building block every
time the trigger model encounters it, except for the first time.
Type TSP-Link accessible Affected by Where saved Default value
Instrument reset
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_BRANCH_ONCE_EXCLUDED,
branchToBlock)
The sequence of the block in the trigger model
The block number of the trigger model block to execute when
the trigger model encounters this block after the first encounter
