6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
6-30 DMM7510-901-01 Rev. B / May 2015
Example
:CALC2:VOLT:LIM1:CLE:AUTO OFF
:CALC2:VOLT:LIM1:AUD FAIL
:CALC2:VOLT:LIM1:LOW 0.25
:CALC2:VOLT:LIM1:UPP 2.5
:CALC2:VOLT:LIMIT1:STAT ON
:READ?
:CALC2:VOLT:LIMIT1:FAIL?
:CALC2:VOLT:LIM1:CLE
Set limit autoclear off.
Enable the beeper for limit 1 when a voltage
measurement exceeds the limit.
Set lower limit 1 for voltage to 0.25 V.
Set upper limit 1 for voltage to 2.5 V.
Enable limit 1 testing for voltage.
Make a reading; the limit is checked and results
display on the front panel
Return the test results; example output if the test
fails on the low limit:
LOW
Also see
:CALCulate2:<function>:LIMit<Y>:CLEar:AUTO (on page 6-23)
:CALCulate2:<function>:LIMit<Y>:CLEar[:IMMediate] (on page 6-24)
:CALCulate2:<function>:LIMit<Y>:FAIL? (on page 6-26)
:CALCulate2:<function>:LIMit<Y>:LOWer[:DATA] (on page 6-27)
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] (on page 6-30)
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA]
This command specifies the upper limit for a limit test.
Type Affected by Where saved Default value
Instrument reset
Power cycle
Measure configuration list
Measure configuration list
functions; see Details
Usage
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] <n>
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] DEFault
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] MINimum
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA] MAXimum
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA]?
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA]? DEFault
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA]? MINimum
:CALCulate2:<function>:LIMit<Y>:UPPer[:DATA]? MAXimum
The function to which the setting applies; see Functions
Limit number:
or
The value of the upper limit (-1e+12 to 1e+12)
