6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-110 DMM7510-901-01 Rev. B / May 2015
[:SENSe[1]]:<function>:THReshold:RANGe
This command indicates the expected input level of the voltage signal.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
10 V
Usage
[:SENSe[1]]:<function>:THReshold:RANGe <n>
[:SENSe[1]]:<function>:THReshold:RANGe DEFault
[:SENSe[1]]:<function>:THReshold:RANGe MINimum
[:SENSe[1]]:<function>:THReshold:RANGe MAXimum
[:SENSe[1]]:<function>:THReshold:RANGe?
[:SENSe[1]]:<function>:THReshold:RANGe? DEFault
[:SENSe[1]]:<function>:THReshold:RANGe? MINimum
[:SENSe[1]]:<function>:THReshold:RANGe? MAXimum
<function>
The function to which the setting applies; see Functions
<n>
The range: 0.1 to 700; instrument selects nearest valid range (100 mV, 1 V, 10 V,
100 V, 700 V)
Functions
VOLTage[:DC]
RESistance
TEMPerature
VOLTage[:DC]:RATio
VOLTage:AC
FRESistance
CONTinuity
DIGitize:VOLTage
CURRent[:DC]
DIODe
FREQuency[:VOLTage]
DIGitize:CURRent
CURRent:AC
CAPacitance
PERiod[:VOLTage]
Details
The range setting conditions the signal. The instrument automatically selects the most sensitive
threshold range for the value you enter. For example, if you specify the expected input voltage to be
90 mV, the instrument automatically selects the 100 mV threshold range.
Example
FREQ:THR:RANG 90
Set the threshold range for frequency to 90 V,
which will select the 100 V range.
Also see
[:SENSe[1]]:<function>:THReshold:LEVel (on page 6-109)
[:SENSe[1]]:<function>:THReshold:RANGe:AUTO (on page 6-111)
