7½ Digit Graphical Sampling Multimeter Reference Manual Section 8:
DMM7510-901-01 Rev. B / May 2015 8-275
Example
trigger.lanin[1].edge = trigger.EDGE_FALLING
Set the edge state of LAN event 1 to falling.
Also see
Digital I/O (on page 3-47)
TSP-Link system expansion interface (on page 3-104)
trigger.lanin[N].overrun
This attribute contains the overrun status of the LAN event detector.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (R) Yes LAN trigger N clear Not applicable Not applicable
Usage
overrun = trigger.lanin[N].overrun
The trigger overrun state for the specified LAN packet (
or
)
The LAN event number (1 to 8)
Details
This command indicates whether an event has been ignored because the event detector was already
in the detected state when the event occurred.
This is an indication of the state of the event detector built into the synchronization line itself. It does
not indicate if an overrun occurred in any other part of the trigger model, or in any other construct that
is monitoring the event.
It also is not an indication of an output trigger overrun.
Example
overrun = trigger.lanin[5].overrun
print(overrun)
Checks the overrun status of a trigger on LAN5 and
outputs the value, such as:
Also see
trigger.lanin[N].clear() (on page 8-274)
trigger.lanin[N].wait() (on page 8-276)
trigger.lanout[N].assert() (on page 8-276)
trigger.lanout[N].stimulus (on page 8-282)
