Model DMM7510

7½ Digit Graphical Sampling Multimeter Reference Manual Section 8:

TSP command reference

DMM7510-901-01 Rev. B / May 2015 8-343

Details

Setting the pulse width to 0 asserts the trigger indefinitely.

Example

tsplink.line[3].mode = tsplink.MODE_TRIGGER_OPEN_DRAIN

trigger.tsplinkout[3].pulsewidth = 20e-6

Sets pulse width for trigger

line 3 to 20 μs.

Also see

trigger.tsplinkout[N].assert() (on page 8-341)

trigger.tsplinkout[N].release() (on page 8-343)

tsplink.line[N].mode (on page 8-348)

trigger.tsplinkout[N].release()

This function releases a latched trigger on the given TSP-Link trigger line.

Type TSP-Link accessible

Affected by Where saved Default value

Function

Yes

Usage

trigger.tsplinkout[N].release()

The trigger line (1 to 3)

Details

Releases a trigger that was asserted with an indefinite pulse width. It also releases a trigger that was

latched in response to receiving a synchronous mode trigger.

Example

tsplink.line[3].mode =

tsplink.MODE_TRIGGER_OPEN_DRAIN

trigger.tsplinkout[3].release()

Releases trigger line 3.

Also see

trigger.tsplinkout[N].assert() (on page 8-341)

tsplink.line[N].mode (on page 8-348)
