[:SENSe[1]]:<function>:ATRigger:WINDow:DIRection
This command defines if the analog trigger occurs when the signal enters or leaves the defined upper and lower
analog signal level boundaries.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
ENTer
Usage
[:SENSe[1]]:<function>:ATRigger:WINDow:DIRection <setting>
[:SENSe[1]]:<function>:ATRigger:WINDow:DIRection?
<function>
The function to which the setting applies; see Functions
<setting>
The direction:
• Enter: ENTer
• Leave:
LEAVe
Functions
VOLTage[:DC]
RESistance
TEMPerature
VOLTage[:DC]:RATio
VOLTage:AC
FRESistance
CONTinuity
DIGitize:VOLTage
CURRent[:DC]
DIODe
FREQuency[:VOLTage]
DIGitize:CURRent
CURRent:AC
CAPacitance
PERiod[:VOLTage]
Details
This is only available when the analog trigger mode is set to window.
Example
FUNC "CURR"
CURR:RANGE 3
CURR:AZER OFF
CURR:ATR:MODE WINDOW
CURR:ATR:WIND:LEV:HIGH 2.5
CURR:ATR:WIND:LEV:LOW 1
CURR:ATR:WIND:DIR LEAV
Set measure function to DC current.
Set range to 3 A.
Disable autozero.
Set the analog trigger mode to window.
Set the analog trigger level for the low point of
the window to 1.0 A and the high point for 2.5 A.
Set the trigger to occur when the signal leaves
the window (signal below 1.0 A or above 2.5 A).
Also see
Analog triggering overview (on page 3-64)
[:SENSe[1]]:<function>:ATRigger:MODE (on page 6-59)
[:SENSe[1]]:<function>:ATRigger:WINDow:LEVel:HIGH (on page 6-65)
[:SENSe[1]]:<function>:ATRigger:WINDow:LEVel:LOW (on page 6-66)
