7½ Digit Graphical Sampling Multimeter Reference Manual Section 6: SCPI command re
DMM7510-901-01 Rev. B / May 2015 6-203
All items in the list are subject to the same action; you cannot combine AND and OR logic in a single
block.
You cannot leave the first event as no trigger. If the first event is not defined, the trigger model errors
when you attempt to initiate it.
The following usage has been deprecated; replace it with the usage above that includes the clear
parameter.
:TRIGger:BLOCk:WAIT <blockNumber>, <event>, <logic>, <event>
:TRIGger:BLOCk:WAIT <blockNumber>, <event>, <logic>, <event>, <event>
The following table shows the constants for the events.
Trigger events
Event description Event constant
No trigger event
Front-panel TRIGGER key press
Notify trigger block <n> (1 to 8); the trigger model generates a
trigger event when it executes the notify block
A command interface trigger (bus trigger):
• Any remote interface: *TRG
• GPIB only: GET bus command
•
VXI-11: VXI-11 command device_trigger
Line edge (either rising, falling, or either based on the
configuration of the line) detected on digital input line
(1 to 6)
Line edge detected on TSP-Link synchronization line <n> (1 to 3)
Appropriate LXI trigger packet is received on LAN trigger object
<n>
(1 to 8)
Trigger event blender <n> (1 or 2), which combines trigger events
Trigger timer <n> (1 to 4) expired
Example 1
:TRIGger:BLOCk:WAIT 9, DISP
Set trigger model block 9 to wait for a user to
press the TRIGGER key on the front panel
before continuing and to act on a recorded
TRIGGER key event that gets detected either
before or after reaching block 9.
Example 2
:TRIGger:BLOCk:WAIT 9, DISP, ENTer
Set trigger model block 9 to wait for a user to
press the TRIGGER key on the front panel
before continuing and to act only on a recorded
TRIGGER key event that gets detected when
Also see
Wait block (on page 3-76)
