Section

8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter

Reference Manual

8-302 DMM7510-901-01 Rev. B / May 2015

allPattern

The bit pattern that is sent when all limits have failed; 1 to 15; default is 15

startInLine

The input line that starts the test; 5 for digital line 5, 6 for digital line 6, or 7 for external

in; default is 5

startDelay

The delay time before each measurement (167 ns to 10 ks); default is 0 for no delay

endDelay

The delay time after the measurement (167 ns to 10 ks); default is 0 for no delay

bufferName

The name of the reading buffer, which may be a default buffer (defbuffer1 or

defbuffer2) or a user-defined buffer; defaults to defbuffer1

Details

This trigger model template allows you to sort components and place them into up to four bins, based

on the comparison to limits.

To set a limit as unused, set the high value for the limit to be less than the low limit.

All limit patterns and the all fail pattern are sent on digital I/O lines 1 to 4, where 1 is the least

significant bit.

The out line of the EXT TRIG IN/OUT rear-panel terminal is asserted at the end of each

measurement.

After selecting a trigger model template, you can view the trigger model blocks in a graphical format

by pressing the front-panel MENU key and under Trigger, selecting Configure. You can also add or

delete blocks and change trigger model settings from this screen. You can use the

trigger.model.getblocklist() command to view the trigger model blocks in a list format.

Example

For a detailed example, see the section in the Model DMM7510 User's Manual named "Grading and

binning resistors."

Also see

None
