9.2.2 Signal ow

Interpolation

Target position

Velocity offset

Torque offset

Position

controller

Speed ctrl.: Load I component

Position actual value

Positive torque limit value

Negative torque limit value

Speed

limitation

Speed

controller

Torque

limitation

Encoder

evaluation

Field-orientated

control

Torque actual valueVelocity actual value

Congure posion control

Operang mode "CiA 402 Cyclic sync posion mode (csp)"

Signal ow
