12 Conguring the feedback system
This chapter provides informaon on how to use feedback systems.
The inverter can be equipped to allow the connecon of up to two independent feedback sys-
t
ems.
Each of the two feedback systems
•
Is placed in a designa
ted slot in the lower part of the inverter
•
Has an encoder connecon on its front side
•
Is an oponal equipment feature of the inverter
Anschluss Lastgeber
oder Leitgeber
Anschluss Motorgeber
A
B
At the me of commissioning, the feedback system is already specied by the hardware of the
respecve device version.
Please note that one of two sets of parameters will be eecve depending on
which f
eedback system opon has been selected: either the parameters for
resolver evaluaon or the parameters for encoder evaluaon.
Conguring the feedback system
175
