7 Conguring the "Electronic Gearbox" TA
The technology applicaon Electronic Gearbox is used in the following applicaon range:
•
Sliers
•
Calender driv
es
•
Line drives
•
Transport belts
•
Vibrators
•
Roller plants
•
Stretching machines
•
Wire drawing systems
The "Electronic Gearbox" technology applicaon allows a synchronism with adjustable
s
tretching rao to be realised between the drives.
•
The c
onversion rao is freely adjustable. The conversion rao is
specied in the form of a
fracon (numerator/denominator).
•
The master value selecon can be performed using various interfaces:
•
Virtual master
•
System bus
•
Interface applicaon feedback B
The electronic gearbox is set up using the following funcons:
4Virtual master ^ 103
4Clut
ching with basic speed ^ 120
4Connecng the velocity oset ^ 122
4Velocity synchronizaon ^ 117
4
Posion trimming ^ 124
The technology applicaon can also be used for the status display and error message, or to
reset an error.
The technology applicaon "Electronic Gearbox" only supports "modulo" axes. This means:
•
The mas
ter axis must be a "modulo" axis.
•
The slave axis must be a "modulo" axis.
Seng of the control mode
The control mode of the slave axis is congured by seng the parameter De
fault control
mode to "Posion control motor encoder [0]”; otherwise, the axis will dri at standsll.
40x500A:090
ManualJog
t
n
System bus
Application
feedback (B)
Virtual Master
Torque Limitation
M
Slave
Offset
+
Trimming
∆ p
HALT
t
n
Halt
STOP
t
n
QSP A
pplication
Fig. 32: Signal ow in the technology applicaon
In the "Technology applicaon" dialogue of the »EASY Starter« soware, the parameter Appli-
caon
selecon shows which technology applicaon is acve. The technology applicaon can
be modied in this dialogue. 40x4000
Conguring the "Electronic Gearbox" TA
91
