13.5.3.3 Torque feedforward control
P
arameter
Address Name / seng range / [default seng] Info
0x2820:009 Holding brake control: Starng torque source Seng of the source for the holding brake starng torque.
0 Last torque saved The stopping value saved automacally during the last closing operaon
is used as starng torque.
1 Torque in 0x2820:010 The parameterised starng torque is used (0x2820:010).
0x2820:010 Holding brake control: Starng torque
-3276.8 ... [0.0] ... 3276.7 %
Seng of the feedforward control value for the automac
operaon
(0x2820:009 = 1).
0x2820:021 Holding brake control: Detected actual torque
•
Read only: x.x %
Display of the torque actual value that is used for the feedforward con-
trol. 0x2820:009 = 0
13.5.3.4 Manual brake control
The holding brake can be released and applied manually independently of the operang mode
and operang status of the inverter. This funcon can be used, for instance, to move the axis
manually in the e
vent of an error.
Details
The following sengs are possible:
•
Open the holding brake:
-
The holding brake remains open unl it closed again manually.
•
Close the holding brake.
•
Release the holding brake for a xed me by a start signal and then apply it automacally:
-
Time f
or "Brake released": 0x2820:019
-
Start signal: 0x2820:020, bit 0 = 1
-
Aer the
me has elapsed → bit 0 = 0
Parameter
Address Name / seng range / [default seng] Info
0x2820:011 Holding brake control: Override of the brake control Mode for override or forced opening/closing of the holding brake irre-
specve of the operang mode.
In the e
vent of an error and acvated funcon for forced opening, the
brake is not applied.
0 No override acve Mode for override or forced opening/closing of the holding brake irre-
specve of the operang mode.
1 Open brake
•
In the e
vent of an error and acvated
funcon for forced opening, the
brake is not applied.
2 Close brake
3 Test pulse
0x2820:020 Holding brake control: Brake control word
0x00 ... [0x00] ... 0xFF
Control word for the holding brake.
Bit 0 Transmit test signal
Conguring the motor control
P
arameterisable motor funcons
Holding brake control
232
