6.1.5 Motor/encoder feed constant
The feed constant corresponds to the machine moon for one revoluon of the gearbox out-
put sha.
When a turntable is used, the feed constant is = 360°/revoluon when dened as an angle.
The feed constant of a conveyor drive results from the circumference of the drive roll.
M
d=200 mm
Calculaon of the feed constant
V
K
n
d
p*
=
Symbol Descripon
F
C
Feed constant
d Diameter
n Revoluon
Example:
The feed constant of a spindle drive (linear axis) results from the leadscrew pitch. The feed
constant indicates the distance travelled by the slide in one revoluon (in the following exam-
ple 5,023 mm).
M
h = 5.023 mm
Fig. 2: Feed constant of a spindle drive
h Leadscrew pitch from the technical data of the linear axis
The kinemac parameters for the second encoder can be used to dene how an imported
enc
oder posion or encoder speed should be converted into machine units.
Parameter
Address Name / seng range / [default seng] Info
0x500A:032 Feed constant
0.0001 ... [360.0000] ... 214748.3647
•
Seng can only be changed if the inverter is inhibi-
t
ed.
0x500B:032 Feed constant
0.0001 ... [360.0000] ... 214748.3647
•
Seng can only be changed if the inverter is inhibi-
ted.
Technology applicaon (TA) basic sengs
Kinemac sengs
Motor/encoder feed constant
49
