16.3 PROFINET
PROFINET® (Process Field Network) is a real-me capable eldbus system based on Ethernet.
•
PR
OFINET® is a registered trademark and patented technology licensed by the PROFIBUS &
PROFINET Internaonal (PI) user
organisaon.
•
De
tailed informaon on PROFINET can be found on the web page of the user organisaon:
hp://www.probus.com
•
PROFINET transmits parameter data,
conguraon data, diagnosc data, alarm messages,
and process data between the IO-Devices and the IO-Controller (PLC).
•
The data is transmied as a funcon of its me-crical behaviour via corresponding com-
municaon channels.
•
The inverter is implemented as IO-Device into a PROFINET-RT network.
•
The PROFINET connecons are carried out as standard RJ45 sockets.
•
Further informaon about the dimensioning of a PROFINET network can be found in the
conguraon document for the inverter.
Precondions
•
The in
verter is equipped with the "PROFINET" network opon.
•
The inverter has not been parametrised as a CiA 402 moon drive. Technology applicaon
selected with parameter 0x4000.
PROFINET
connecon
•
The PR
OFINET connecon is established via the RJ45 sockets X2x6 and X2x7.
•
F
or establishing the connecon to the network, a common standard Ethernet cable from
CAT 5/5e is suitable.
Typical topologies
Line Tree
C
R
Dn
D2D1
C
SWn
SW2
SW1
Ring
C
Dn
D2
D1
D3
R
SW
C IO controller SW Switch SCALANCE (MRP capable)
D IO device R Redundant domain
Conguring the network
PR
OFINET
330
