13.9.3 Overcurrent monitoring
This funcon monitors the instantaneous value of the motor current and serves as motor pro-
tecon.
WARNING!
With an incorrect
parameterisaon, the maximum permissible motor current may be excee-
ded in the process.
Possible consequences: irreversible damage of the motor.
Avoid motor damages by using the overcurrent monitoring funcon as follows:
▶
The seng of the threshold for the overcurrent monitoring in 0x2D46:001 must be adapted
to the connected motor.
▶
Set the maximum output current of the inverter in 0x6073 much lower than the threshold
for overcurrent monitoring.
Condions for using this funcon
This funcon is suitable for a synchronous motor.
Parameter
Address Name / seng range / [default seng] Info
0x2D46:001 Overcurrent monitoring: Threshold
0.0 ... [5.4] ... 3000.0
A
•
If the acve motor current exceeds the set threshold, the response
set in 0x2D46:002 is eected for the purpose of motor protecon.
•
The par
ameter can also be set and overwrien by selecng a motor
fr
om the "motor catalog" of the engineering tool.
0x2D46:002 Overcurrent monitoring: Response Selecon of the response to the triggering of motor current monitoring.
Associated error code:
•
9092 | 0x2384 - RANLI_CIMES_0500_03891
0 No response
1 Fault > CiA402
2 Warning
13.9.4 Motor phase failure detecon
The motor phase failure detecon funcon can be acvated for both synchronous and asyn-
chr
onous motors.
In the Lenze
seng, monitoring is not acvated!
Precondions
Motor phase failure detecon during operaon is suitable for applicaons which are operated
with a c
onstant load and speed. In other cases, transient processes or unfavourable operang
points can cause erroneous triggering to occur.
Parameter
Address Name / seng range / [default seng] Info
0x2D45:001 Motor phase failure detecon: Response - Motor
phase 1
Selecon of the response following the detecon of a motor phase fail-
ur
e during operaon.
Associated error codes:
•
65289 | 0xFF09 - Motor phase missing
•
65290 | 0xFF0A - Motor phase failure phase U
•
65291 | 0xFF0B - Motor phase failure phase V
•
65292 | 0xFF0C - RANLI_CIMES_1000_20883
0 No response
1 Fault > CiA402
2 Warning
Conguring the motor control
Mot
or protecon
Overcurrent monitoring
274
