13.6.2 Tuning of the motor and the speed controller

The following describes in general how to opmise the speed controller. This may be required

if some par

ameters have on the load side of the drive system have changed or have not been

set yet, such as:

•

Mot

or moment of inera

•

Load moment of inera

•

Type of coupling between motor moment of inera and load moment of inera

Precondions

All rated motor data is known and set in the inverter, either by selecng the motor from the

mot

or catalogue or manually.

4Select motor from motor catalogue ^ 39

4Manual seng of the motor data ^ 41

Required steps

Adapt the following parameters to your drive system using the engineering tool. Since this

only changes load-dependent data, the other parameter groups do not need to be calculated

again.

In the engineering tool, the speed control sengs can be conrmed via the Inialise buon.

This funcon is not available via the keypad.

Conguring the motor control

Opons for opmising the control loops

uning of the motor and the speed controller
