13.2 Servo control for asynchronous motor (SC-ASM)
The motor control is based on a feedback, eld-oriented and cascaded controller structure
and enables a dynamic and s
table operaon in all four quadrants.
Precondions
•
The ser
vo control (SC ASM) is only suitable for asynchronous motors.
•
The servo control (SC ASM) requires a feedback of the posion.
13.2.1 Required commissioning steps
1.
Check wiring by means of manual test modes: Tesng the motor control ^ 277
2.
Acvate motor control type: 0x2C00 = "Servo control (SC ASM) [2]".
3.
Set motor data: Motor data ^ 38
4.
Conguring the feedback system ^
175
5.
Only required for motors of other manufacturers:
•
Set and opmise current controller: Curr
ent controller ^ 243
•
Correcon of the stator leakage inductance (Lss)... ^ 251
6.
Only required for an automac calculaon of the speed controller parameters:
•
Dene total moment of inera: Tuning of the motor and the speed controller ^ 234
7.
Set speed controller: Speed controller ^ 240.
8.
Set posion controller:
Posion controller ^ 249
9.
Only required for motors of other manufacturers:
•
Set eld controller: ASM eld controller ^ 245
•
Se
t eld weakening controller: ASM eld weakening controller ^ 246
10.
Oponal: Correcon of the stator leakage inductance (Lss)... ^ 251
11.
Oponal: As
ynchronous motor (ASM): Idenfy Lh saturaon characterisc ^ 257
12.
Oponal:
Esmate opmum magnesing current ^ 259
13.
Oponal: Jerk limitaon ^ 260
14.
Oponal: Not
ch lter (band-stop lter) ^ 261
15.
Oponal: DC br
aking ^ 227
13.3 Sensorless control for synchronous motor (SL-PSM)
13.3.1
Required commissioning steps
1.
Oponal: Acvate ying restart circuit:
•
From rmware version 4 onwards, a ying restart circuit for the synchronous motor up
to speeds lower than half the rated speed is supported.
•
If the ying restart circuit shall be used, set the start method "Flying restart circuit [2]"
in . More sengs are not required for the ying restart circuit at sensorless control of a
synchronous motor.
2.
Oponal for a speed control with torque limitaon in operang mode 0x6060 = "MS:
Velocity mode [-2]":
•
Select the source in for the posive torque limit source and set it accordingly.
The torque
limitaon (parameter 0x2949:001/002) can only be used for open-
loop controlled operaon of the SL-PSM, not for closed-loop controlled opera-
on.
•
Select the sour
ce in for the negave torque limit source and set it accordingly.
Conguring the motor control
Sensorless control for synchronous motor (SL-PSM)
Required commissioning steps
214
