Address Name / seng range / [default seng] Info
0x2B03:001 Voltage grid points (y) user V/f characterisc: y1 = U01
(x = f01)
0.00 ... [400.00] ... 1000.00
V
Freely parameterisable V/f characterisc (values for Y axis).
0x2B03:002 Voltage grid points (y) user V/f characterisc: y2 = U02
(x = f02)
0.00 ... [320.00] ... 1000.00 V
0x2B03:003 Voltage grid points (y) user V/f characterisc: y3 = U03
(x = f03)
0.00 ... [240.00] ... 1000.00
V
0x2B03:004 Voltage grid points (y) user V/f characterisc: y4 = U04
(x = f04)
0.00 ... [160.00] ... 1000.00
V
0x2B03:005 Voltage grid points (y) user V/f characterisc: y5 = U05
(x = f05)
0.00 ... [80.00] ... 1000.00 V
0x2B03:006 Voltage grid points (y) user V/f characterisc: y6 = U06
(x = f06)
0.00 ... [0.00] ... 1000.00 V
0x2B03:007 Voltage grid points (y) user V/f characterisc: y7 = U07
(x = f07)
0.00 ... [80.00] ... 1000.00 V
0x2B03:008 Voltage grid points (y) user V/f characterisc: y8 = U08
(x = f08)
0.00 ... [160.00] ... 1000.00 V
0x2B03:009 Voltage grid points (y) user V/f characterisc: y9 = U09
(x = f09)
0.00 ... [240.00] ... 1000.00 V
0x2B03:010 Voltage grid points (y) user V/f characterisc: y10 =
U10 (x = f10)
0.00 ... [320.00] ... 1000.00 V
0x2B03:011 Voltage grid points (y) user V/f characterisc: y11 =
U11 (x = f11)
0.00 ... [400.00] ... 1000.00
V
13.4.4 Acvate voltage vector control (Imin controller)
The voltage vector control is used if a comparavely high starng torque must be provided.
This funcon ensures that the required motor current is maintained in the lower speed range.
NOTICE
The boost funcon described here adds to the 4Se
t voltage boost funcon. ^ 221
Only set one of the two "boost" funcons.
▶
Recommendaon: torque increase in the lower speed range
▶
Take into consideraon that the increased current at low speeds also entails higher heat los-
ses of the motor.
•
The v
oltage vector control is acvated by dening a current setpoint.
•
F
or the automac calculaon of the control parameters, the "Calculate Imin controller"
funcon is provided via parameter .
Parameter
Address Name / seng range / [default seng] Info
0x2B04 V/f boost controller - current setpoint
0.00 ... [0.00] ... 500.00 A
Seng of the current setpoint for the voltage vector control.
•
The
seng "0.00 A" deacvates the voltage vector control.
•
When dening the current setpoint, we recommend you to provide a
reserve of 20 % in order to largely exclude a "stalling" of the motor
caused by unexpected addional loads.
•
Example of starng torque = rated motor torque: set the current set-
point to approx. 120 % of the load current.
Conguring the motor control
V
/f characterisc control for asynchronous motor (VFC open loop)
Dene V/f characterisc shape
219
