12.4.3 Pole
posion idencaon (PPI) with minimum movement
DANGER!
Mechanical damage of the motor caused by hanging loads!
The mot
or may be permanently damaged.
The motor must not be braked or blocked during the pole posion idencaon. Thus, this
funcon must not be used for hanging loads!
NOTICE
Thermal overload of the motor!
The mot
or may be permanently damaged.
Before execung the pole posion idencaon, check that the following monitoring sys-
tems are parameterised correctly in order to prevent a permanent damage of the motor in
the event of an error:
4Motor overload monitoring (i²*t) ^ 264
Overcurrent monitoring
Funconal
descripon
If servo control for synchronous motor is set and if no error is pending, the current posion is
memorised aer controller enable, and the current is increased along a ramp for 10 s to 35 %
of the rated motor current. This will cause the rotor to align, which, however, is compensated
by a posion control. If the rotor makes an electrical movement of more than 20°, an error
message is output, and the value measured is discarded. This might occur in the case of
motors with considerable detent torques.
If the current has reached its nal value, a plausibility check is executed aer a short interval:
in order to detect a non-permissible blocking of the motor, a posive and a negave test angle
(± 20°) relave to the current posion are dened aer the idencaon. The motor must
align itself to these two test angles within a tolerance of 25 %.
Condions for the execuon
The mot
or must not be braked or blocked during the pole posion idencaon.
The servo inverter is error-free and in Switched on device state.
Response of the motor during performance
The
moon of the motor will maximally correspond to the set "Max. permissible moon"
(Lenze seng: 20°). If a greater moon is detected via the encoder system, the pole posion
idencaon is cancelled and the parameterised error response (Lenze seng: Fault) is trig-
gered.
How to execute the pole posion idencaon PLI (min. movement):
1.
If the ser
vo inverter is enabled, disable it.Enable operaon
2.
Se
t the object 0x2825 to "6" to change to the "pole posion idencaon PLI (min. move-
men
t)" operang mode.
3.
Enable the servo inverter to start the process.
Note: Inhibing the controller serves to abort the started procedure any me if required
without changing the sengs.
Conguring the feedback system
Synchronous motor: Pole posion idencaon (PPI)
Pole posion idencaon (PPI) with minimum movement
207
