Lenze I95AE240F User Manual

15.1 Basic seng
Precondions
•
The wir
ed
communicaon with the inverter has been established.
•
If this condion is not met, read more detailed notes in secon "Generate a connec-
on between inverter and »EASY Starter«". ^ 30
•
The PC with the installed »EASY Starter« is started.
Automac conguraon
By default, the engineering port of the inverter receives its IP address automacally from a
DHCP server. By pressing the "DHCP" buon, the 0x2451:004 parameter is acve ("enabled").
Now, the IP conguraon is completed. The inverter can be accessed via the Ethernet connec-
on.
Manual conguraon
Make sure to press the "Restart with current values" buon every me you
chang
e the values.
The engineering port must be congured when a stac address is to be assigned.
For this purpose, the "DHCP" buon must bet set to the "Disabled" state.
The following parameters can be entered in the »EASY Starter«:
•
IP addr
ess
•
Network mask
•
Gateway address
Using a conguraon le
A
le named "ip.txt" can be used to reset the IP address. This le must be stored on the SD
card in the root directory.
The network sengs are evaluated and accepted when the inverter is started. The le is then
renamed as "ip_old.txt".
The structure of the text le can look as follows:
-
192.168.101.221
-
255.255.255.0
-
192.168.101.1
If the stac IP address is to be reset to DHCP, only the content of the ip.txt le must be set to
"DHCP". This serves to use DCHP for a dynamic address allocaon at next boot.
Parameter
Address Name / seng range / [default seng] Info
0x2450 Engineering port control Acvaon of the engineering port sengs (Ethernet).
0 No acon/No error
1 Restart with current values
10 Busy
11 Cancelled
12 Faulted
0x2451:001 Engineering port sengs: IP address
0.0.0.0 ... [0.0.0.0] ... 255.255.255.255
Seng of the IP address.
The de
fault seng 276605120 corresponds to the IP address
192.168.124.16.
•
276605120 = 0x107CA8C0 à 0xC0.0xA8.0x7C.0x10
= 192.168.124.16
0x2451:002 Engineering port sengs: Subnet
0.0.0.0 ... [0.0.0.0] ... 255.255.255.255
Seng of the subnet mask.
The de
fault seng 16777215 corresponds to the subnet mask
255.255.255.0.
•
16777215 = 0xFFFFFF à 0xFF
.0xFF.0xFF.0x00 = 255.255.255.0
Congure engineering port
Basic seng
289
