Address Name / seng range / [default seng] Info
0x2C54:006 Load encoder/master encoder idencaon
(Resolver): Idencaon status
•
R
ead only
Display of the resolver idencaon status.
Bit 0 Idencaon acvated TRUE if:
•
Idencaon has been started.
•
Controller enable is acve.
FALSE if:
•
Idencaon has been aborted or completed successfully.
•
A meout error is acve.
•
The 24V supply has been s
witched on and default sengs are loaded.
Bit 1 Constant speed detected TRUE if:
•
A c
onstant motor speed has been detected.
FALSE if:
•
Idencaon has been aborted or completed successfully.
•
A meout error is acve.
•
The 24V supply has been s
witched on and default sengs are loaded.
Bit 2 Idencaon is running TRUE if:
•
Idencaon is running.
F
ALSE if:
•
The motor speed has fallen below the minimum speed of 500 rpm.
•
The idencaon process has been aborted temporarily and is on
standby.
Bit 3 Idencaon successful TRUE if:
•
Idencaon has been completed successfully.
FALSE if:
•
The idencaon is not completed yet aer default sengs were loa-
ded.
Bit 4 Idencaon failed TRUE if:
•
A
meout error has occurred.
FALSE if:
•
Idencaon has been completed successfully.
12.2.3 Encoder
sengs
In general, an encoder is a measuring system which serves to detect the velocity/speed and
possibly the posion of a kinemacs or motor.
Details
If a resolver variant is to be plugged into the respecve slot of the inverter as a
f
eedback system, the parameters in this secon have no funcon.
Generally, an encoder can be used for a variety of tasks:
•
As se
tpoint encoder for dening a speed / frequency setpoint.
•
As setpoint encoder for dening a posion setpoint.
•
As setpoint encoder for dening a setpoint for the process controller.
•
As actual value encoder for feeding back the variable for the process controller.
•
As kinemacs encoder (feedback system).
Parameter
Address Name / seng range / [default seng] Info
0x2C50 Load encoder/master encoder type
•
Seng can only be changed if the inverter is inhibi-
t
ed.
Selecon of the encoder type.
1 SinCos encoder
2 Hiperface absolute value encoder
5 SSI encoder
0x2C52:001 Load encoder/master encoder sengs (encoder):
Increments/revoluon
1 ... [1024] ... 131072
•
Seng can only be changed if the inverter is inhibi-
ted.
Seng of the encoder number of increments (according to manufac-
turer data/encoder data sheet).
Conguring the feedback system
Sec
ond feedback system for the techology applicaon
Resolver sengs
193
