Lenze I95AE240F User Manual

20.3 3-phase mains connecon 480 V
20.3.1
Rated data
Inverters I95AE155F I95AE175F I95AE222F I95AE240F I95AE275F I95AE311F I95AE315F
Rated power kW 0.55 0.75 2.2 4 7.5 11 15
Rated power hp 0.75 1 3 5 10 15 20
Mains voltage range 3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0-480 V
Rated mains current
without mains choke A 2.1 2.8 6.5 10.5 16.6 23.7 -
with mains choke A 1.7 2.2 4.4 7.5 13.1 18.6 24
Apparent output power kVA 1.2 1.6 3.8 6.4 11 16 22
Rated output current
2 kHz A 1.6 2.1 4.8 8.2 14 21 27
4 kHz A 1.6 2.1 4.8 8.2 14 21 27
8 kHz A 1.6 2.1 4.8 6.2 14 21 19.8
16 kHz A 1.1 1.4 2.2 2.5 7.8 7.8 7.2
Power loss
2 kHz W 38 44 76 116 186 256 342
4 kHz W 39 46 80 122 197 272 363
8 kHz W 45 54 99 154 252 351 471
16 kHz W 45 54 99 154 252 351 471
at inverter disable W 20 20 20 20 20 20 20
Cyclic mains switching 3 mes per minute
Max. motor cable length shielded
Category C2 (2 kHz, 4 kHz, 8
kHz)
m 20 20 20 20 20 20 20
Category C3 (2 kHz, 4 kHz, 8
kHz)
m 35 35 35 35 35 35 35
without EMC category m 50 50 50 50 100 100 100
Weight kg 1.6 1.6 1.6 1.6 3.9 3.9 3.9
Weight lb 3.5 3.5 3.5 3.5 8.6 8.6 8.6
Technical data
3-phase mains connecon 480 V
Ra
ted data
436
