16.2.3 Process data transfer
•
Pr
ocess data is cyclically transferred between the EtherCAT master and the slaves (perma-
nent exchange of current input and output data).
•
The transfer of process data is me-crical.
•
The process data serve to control the EtherCAT slaves.
•
The process data can be directly accessed by the master. The data in the PLC, for instance,
are directly stored in the I/O area.
•
The contents of the process data are dened via I/O Data mapping (denion of the Ether-
CA
T objects that are to be transmied cyclically).
•
Process data is not saved in the device.
•
Process data is, e. g. setpoints, actual values, control and status words.
The content of this secon is currently being processed.
Conguraon
•
The a
vailable objects can be mapped in the CiA 402
operang mode " CiA: Velocity mode
" (0x6060 = 2) and as dynamic (free) conguraon. The contents can be selected from all
mappable objects.
•
Standard mapping objects for the CiA 402 operang mode " CiA: Velocity mode ":
4Standard mapping ^ 317
•
Mapping objects for a dynamic (free) assignment: 4Dynamic (free) conguraon ^ 317
•
Mapping is executed in the master conguraon and automacally transferred to the
slave.
•
The data format is 0xAAAABBCC (AAAA = index, BB = subindex, CC = length).
16.2.3.1 Standard mapping
The content of this secon is currently being processed.
Standard mapping of the RPDOs in the CiA 402 operang mode " CiA: Velocity mode "
Master à sla
ve
RPDO mapping entry 1 ( CiA: Velocity mode ) CiA: Controlword (0x6040)
RPDO mapping entry 2 ( CiA: Velocity mode ) CiA 402 parameter " Target velocity " (0x6042)
RPDO mapping Entry 1 (freely congurable) Not assigned.
Standard mapping of the TPDOs in the CiA 402 operang mode " CiA: Velocity mode "
Slave à mas
ter
TPDO mapping entry 1 ( CiA: Velocity mode ) CiA: Statusword (0x6041)
TPDO mapping entry 2 ( CiA: Velocity mode ) CiA 402 parameter " Velocity actual value " (0x6044)
TPDO mapping entry 3 ( CiA: Velocity mode ) Error code (0x603F)
TPDO mapping entry 1 (freely congurable) Digital inputs
16.2.3.2 Dynamic (free)
conguraon
The content of this secon is currently being processed.
The freely congurable mapping objects contain an 8 bit dummy entry (0x00050008). This
ensures that each object is transferred cyclically with 16 bits.
16.2.3.3 Further communicaon objects
The content of this secon is currently being processed.
The parameters for the implemented EtherCAT objects are described below.
16.2.3.4 Expert sengs
The content of this secon is currently being processed.
•
The s
ync managers are congured for the cyclic data transfer and the mailbox communica-
on (display in ... ).
•
F
or the communicaon, the I/O data mapping must be congured via ... (for RPDOs) and
... (for TPDOs).
•
The basic sengs for the sync managers are made via ... and ... .
Conguring the network
E
therCAT
Process data transfer
317
