Garmin G3X Touch Installation Manual

190-01115-01 G3X/G3X Touch Installation Manual - GMC 305 Installation
Rev. AC Page 12-3
12.5 Outline and Installation Drawings
Figure 12-2 GMC 305 Outline Drawing
.46 11.6 TYP.
.86 21.8
84.03.31
1.27 32.2
5.34
135.6
1.24
1.69
31.4
13.0.51
.34 8.6
42.9
.080
2.03 TYP.
1.85
47.0
6.25 158.8
2. 1.
DIMENSIONS ARE NOMINAL AND TOLERANCES ARE NOT IMPLIED UNLESS SPECIFICALLY STATED.
DIMENSIONS: INCHES[mm]. METRIC VALUES ARE FOR REFERENCE ONLY.
NOTES:
FRONT SURFACE OF
AIRCRAFT PANEL
