190-01115-01 G3X/G3X Touch Installation Manual - LRU Pinouts
Rev. AC Page 25-39
25.5.17 Temperature Inputs
Some thermocouple inputs are multi-purpose capable and have several configuration options. CHT5/
CHT6, GP6/GP7, MISC TEMP 1/MISC TEMP 2, and Oil Temp can be used for resistive based
temperature sensors. These inputs are configured by the GDU (refer to Section 33.4.19
for GDU 37X
systems and to Section 34.4.26
for GDU 4XX systems).
If installing an ungrounded thermocouple to an Analog In input, a DC reference must be
added to the LO input. This can be accomplished by adding a resistance of 1 MΩ or less
between ground and the Analog In LO input that the ungrounded thermocouple is installed
on.
Pin Name Connector Pin I/O
CHT1 HI J242 24 In
CHT1 LO J242 12 In
CHT2 HI J242 22 In
CHT2 LO J242 10 In
CHT3 HI J242 20 In
CHT3 LO J242 8 In
CHT4 HI J242 18 In
CHT4 LO J242 6 In
CHT5 HI / CHT 1 RESISTIVE HI J242 16 In
CHT5 LO / CHT 1 RESISTIVE LO J242 4 In
CHT6 HI / CHT 2 RESISTIVE HI J242 14 In
CHT6 LO / CHT 2 RESISTIVE LO J242 2 In
EGT1 HI J242 25 In
EGT1 LO J242 13 In
EGT2 HI J242 23 In
EGT2 LO J242 11 In
EGT3 HI J242 21 In
EGT3 LO J242 9 In
EGT4 HI J242 19 In
EGT4 LO J242 7 In
EGT5 HI J242 17 In
EGT5 LO J242 5 In
EGT6 HI J242 15 In
EGT6 LO J242 3 In
