Garmin G3X Touch - GDU 45 X Outline Drawing; Outline and Installation Drawings

190-01115-01 G3X/G3X Touch Installation Manual - GDU 45X Installation
Rev. AC Page 7-5
7.7 Outline and Installation Drawings
Figure 7-3 GDU 45X Outline Drawing
(2X)
2.13
54.2
4.32
109.7
FRONT SURFACE OF PANEL
.58
14.7
10.3
.41
38.7
1.52
1.68
42.6
7.5 .30
.87
22.2
(2X)
6.96
176.8
.88
22.3
(3X)
42.3 1.66
(2X)
54.7
2.15
7.5 .30
7.40
188.0
5.33
135.5
NOTES:
DIMENSIONS: INCHES [mm]1.
DIMENSIONS ARE SHOWN FOR REFERENCE ONLY.2.
FRONT SURFACE OF PANEL
2.70
68.6
3.68
93.4
7.99
203.0
5.93
150.5
