Garmin G3X Touch Installation Manual

190-01115-01 G3X/G3X Touch Installation Manual - G3X w/GSU 25 and/or GAD 29 Drawings
Rev. AC Page 26-8
Figure 26-1.8 GSA 28 - Trim Switch Interconnect Drawing
SINGLE TRIM SWITCHSINGLE TRIM SWITCH
(DISABLE SPEED (DISABLE SPEED
CONTROL IF EQUIPPED)CONTROL IF EQUIPPED)
1111TRIM IN 1TRIM IN 1
1212TRIM IN 2TRIM IN 2
1313TRIM OUT 1TRIM OUT 1
1414TRIM OUT 2TRIM OUT 2
TRIMTRIM
MOTORMOTOR
S
12 VDC12 VDC
DPDT MOMENTARYDPDT MOMENTARY
CENTER OFF, 2ACENTER OFF, 2A
M
P281P281J281J281
GSA 28 SERVOGSA 28 SERVO
DUAL TRIM SWITCHESDUAL TRIM SWITCHES
1111TRIM IN 1TRIM IN 1
1212TRIM IN 2TRIM IN 2
1313TRIM OUT 1TRIM OUT 1
1414TRIM OUT 2TRIM OUT 2
TRIMTRIM
MOTORMOTOR
M
P281P281J281J281
GSA 28 SERVOGSA 28 SERVO
3RD PARTY TRIM3RD PARTY TRIM
MIXING DEVICEMIXING DEVICE
TO TRIMTO TRIM
SWITCH #1SWITCH #1
TO TRIMTO TRIM
SWITCH #2SWITCH #2
USE SWITCHES AS REQUIRED BY 3RD PARTYUSE SWITCHES AS REQUIRED BY 3RD PARTY
TRIM MIXING DEVICE INSTALLATION INSTRUCTIONSTRIM MIXING DEVICE INSTALLATION INSTRUCTIONS

Garmin G3X Touch Specifications

General

Power Input	10-32 VDC
Touchscreen	Yes
Built-in GPS	Yes
AHRS	Yes
Air Data Computer	Yes
Aviation Database	Yes
Terrain Awareness	Yes
Operating Temperature	-20°C to +55°C
Display Size	10.6 inches
Display Type	LCD
Connectivity	Wi-Fi, Bluetooth, USB, RS-232, CAN bus
Engine Monitoring	Yes
Autopilot Compatibility	Yes
Traffic Awareness	Yes
Weather Data	Yes
