190-01115-01 G3X/G3X Touch Installation Manual - GAD 29 Installation
Rev. AC Page 4-2
4.2 Equipment Available
4.2.1 Required Equipment
4.2.2 Additional Equipment Required
The connector kit in Table 4-2 is required to install the unit, it is not provided with the GAD 29 unit.
4.3 General Specifications
See Section 2.2 for power/current specifications, and Section 2.4.1 for dimension/weight specifications.
4.4 Mounting Requirements
The GAD 29 will mount remotely. The GAD 29 will be secured to the airframe using four screws supplied
by the installer. Refer to Section 4.6
for outline and installation drawings.
4.5 Unit Installation
Fabrication of a wiring harness is required. Sound mechanical and electrical methods and practices are
recommended for installation of the GAD 29. Refer to Section 2.3
for wiring considerations, and to
Section 25.1
for pinouts.
1. Mount the unit to a suitable mounting location using (4) #10-32 pan or hex head screws.
2. Assemble the connector backshells and wiring harness.
3. Connect CAN terminator to unit if required (Section 2.3.1.3.3
).
4. Connect backshell connectors.
Table 4-1 GAD 29 Part Numbers
Model
Assembly Part
Number
Unit Only Part
Number
GAD 29 010-01172-00 011-03236-00
Table 4-2 Contents of GAD 29 Connector Kit (011-03271-00)
Item Garmin P/N Quantity
Backshell w/Hdw, Jackscrew, 9 Pin 011-01855-00 1
Backshell w/Hdw, Jackscrew, 25 Pin 011-01855-02 1
Conn, Plug,D-Sub, Crimp Pin, Commercial, 25 CKT 330-00624-25 1
Conn, Rcpt, D-Sub, Crimp Socket, Commercial, 09 CKT 330-00625-09 1
Contact, Socket, Military Crimp, Size 20 336-00022-02 11
Contact ,Pin, Military Crimp, Size 20 336-00024-00 27
