190-01115-01 G3X/G3X Touch Installation Manual - GTP 59 Installation

Rev. AC Page 20-5

20.5 Outline and Installation Drawings

Figure 20-2. GTP 59 O.A. T. Probe Installation Drawing

NOTES:

2. BUBBLE NUMBERS IN THIS DRAWING REFER TO REFERENCE NUMBERS LISTED IN TABLE 20-3.

1. SUPPLIED CABLE LENGTH IS 10’ +/- 6”. CABLE MAY BE CUT TO NEEDED LENGTH OR LENGTHENED

UP TO 25’ (15’ ADDITIONAL) AS NEEDED. USE THREE-WIRE TWISTED SHIELDED CABLING AND HIGH

QUALITY CRIMPED OR SOLDERED CONNECTIONS FROM THE PROBE TO THE EXTENSION WIRE.

SEE NOTE 1
